L HINGES 3″ & 4″

L HINGES 3" & 4"

L HINGES 3" & 4" - Image 2

L HINGES 3" & 4" - Image 3

Categories: Hinges

L HINGES 3″ & 4″

Select Thickness & Code for Specifications

Thickness

L HINGES (3") 1.5
L HINGES (4") 1.5

Code

0101
0102
0103
0104
0105
0106
0107
0108
0109
0110
0111
0112
0113
0114
0115
0116
0117
0118
0119
0120
0121
0122
0123
0124
0125
0126
0127
0128

Clear

Number of Boxes

CODE	SIZE (MM)	SIZE (INCH)	MATT	LOCKING	PCS PER BOX	BOX PER CARTOON	PCS PER CARTOON
L HINGES (3″) (THICKNESS 1.5MM)
0101	75x10x6	3″x 3/8″x 1/4″	Available	Available	30	20	600
0102	75x10x12	3″x 3/8″x 1/2″	Available	Available	30	20	600
0103	75x10x19	3″x 3/8″x 3/4″	Available	Available	30	20	600
0104	75x10x25	3″x 3/8″x 1″	Available	Available	30	20	600
0105	75x12x6	3″x 1/2″x 1/4″	Available	Available	30	20	600
0106	75x12x12	3″x 1/2″x 1/2″	Available	Available	30	20	600
0107	75x12x19	3″x 1/2″x 3/4″	Available	Available	30	20	600
0108	75x12x25	3″x 1/2″x 1″	Available	Available	30	20	600
0109	75x15x6	3″x 5/8″x 1/4″	Available	N/A	30	20	600
0110	75x15x12	3″x 5/8″x 1/2″	Available	N/A	30	20	600
0111	75x15x19	3″x 5/8″x 3/4″	Available	N/A	30	20	600
0112	75x15x25	3″x 5/8″x 1″	Available	N/A	30	20	600
0113	75x19x6	3″x 3/4″x 1/4″	Available	N/A	30	20	600
0114	75x19x12	3″x 3/4″x 1/2″	Available	N/A	30	20	600
0115	75x19x19	3″x 3/4″x 3/4″	Available	N/A	30	20	600
0116	75x19x25	3″x 3/4″x 1″	Available	N/A	30	20	600

L HINGES (4″) (THICKNESS 1.5MM)
0117	100x10x6	4”x 3/8″x 1/4″	Available	N/A	24	20	480
0118	100x10x12	4”x 3/8″x 1/2″	Available	N/A	24	20	480
0119	100x10x19	4”x 3/8″x 3/4″	Available	N/A	24	20	480
0120	100x10x25	4”x 3/8″x 1″	Available	N/A	24	20	480
0121	100x12x6	4”x 1/2″x 1/4″	Available	N/A	24	20	480
0122	100x12x12	4”x 1/2″x 1/2″	Available	N/A	24	20	480
0123	100x12x19	4”x 1/2″x 3/4″	Available	N/A	24	20	480
0124	100x12x25	4”x 1/2″x 1″	Available	N/A	24	20	480
0125	100x19x6	4”x 3/4″x 1/4″	Available	N/A	24	20	480
0126	100x19x12	4”x 3/4”x 1/2″	Available	N/A	24	20	480
0127	100x19x19	4”x 3/4”x 3/4″	Available	N/A	24	20	480
0128	100x19x25	4″x 3/4”x 1″	Available	N/A	24	20	480
